Quick Specifications
Manufacturer Specifications
| P/N | PS-TPT-0750FNFAGA-3 |
| Watts | 750W |
| Max Output Capacity | 750W |
| Color | Black |
| Dimensions | 150mm(W)x86mm(H)x140mm(D) |
| PFC (Power Factor Correction) | Active PFC |
| Power Good Signal | 100-250 msec |
| Hold Up Time | > 17msec at 80% load |
| Input Current | 10A Max. |
| Input Frequency Range | 50Hz-60Hz |
| Input Voltage | 100-240V～ |
| Operating Temperture | 0°C to + 40°C |
| Operating Humidity | 5% to 85% |
| Storage Temperture | -40°C to + 70°C |
| Storage Humidity | 5% to 95% |
| Cooling System | 12cm Hydraulic bearing fan |
| Efficiency | Meet 80 PLUS® Gold at 115Vac input. |
| MTBF | 100 |
| Safety Approval | CE/UKCA/ICES/TUV/LVD/RCM/CB/FCC/cTUVus/BSMI/CCC/BIS/S-MARK |
| PCI-E 6+2PIN | 4 |
| PCI-E 12+4PIN | 1(300W) |
| Protection | OVP/UVP/OCP/OPP/OTP/SCP |
